Product name : Sausage stuffer sausage filler vacuum stuffer sausage making machine
Product No. : 202152810022
             [Next Product]→
Details:

Sausage stuffer/sausage filler/vacuum stuffer/sausage making machine

Product Descriptions:

This full-automatic quantitative vacuum sausage stuffer is filled by vane pump, driven by servo motor, operated by human-machine interface, and equipped with twisting and kinking structure, and its automatic motions are controlled by micro-computer. This machine is able to fill casing products like sausage, ham sausage, ham and etc. and to quantitative twist and kink those products which are wrapped by natural casings, collagen casings and fibrous casings. As well, this machine can fill boxed, bottled or canned product. The automatic blade compensation device in the machine can achieve the quantitative accuracy to ±3mm, and deliver material delicately. And the speed of filling, twisting and kinking, the number of twisting, weight of every segment can be adjusted. The filling process of this machine is under vacuum environment. The hopper could be flipped, which is easier to wash and clean. This machine is manufactured of stainless steel, and essential parts are treated specially, thus they are hard-wearing. And the controlling parts are imported; appearance is treated by advanced surface treatment technology. Those advantages make the machine reasonable structured, convenient to operate, easy to maintain. And at the end, with not mentioned security devices, this is an ideal equipment for meat processing industry.

Main Features:

1. Simple structure in linear type ,easy in installation and maintenance.
2. Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.
3. High pressure double crank to control the die opening and closing.
4. Running in a high automatization and intellectualization,no pollution
5. Apply a linker to connect with the air conveyor ,which can directly online with other machine

Technical Specification:

Model

BG-6000

Power

8kw, 380v/50hz/3 phases

Filling Capacity

6000kg/h (100r/min)

Quantitative accuracy

±2g

Hopper volume

200L

Kink speed

0-500times/min

Quantitative Range

6~9999g

Center height

980~1030mm(adjustable)

Maximum vacuum degree

-0.1Mpa

Machine Weight

550kg

Dimensions

1980x1125x1780mm






FAQ:

 1. Are you a factory or trading company?

   We are the SGS certificated manufacturer, specialized in meat and sausage processing machines field for 20 years.

2. How about the product quality?

   We adopt excellent SUS304 as machine material.

Each machine will be tested more than 24 hours before delivery to you.

All electrical parts are used reliable and famous brand, which works with us over 20 years.

3. What about the warranty and after-sale service?

   Our machine has one year guarantee, whole life technical support engineers are available to serve overseas.

4. Are you providing training about machine installation and operation?

    Yes, our engineer can teach your workers in our or your factory.

5. Is it possible to use our LOGO or special custom design?

    Yes, we have a professional technology team for new research and development.

6. How long the lead time is?

   Usually 1-2 weeks, depends on the machine you ordered.

7. What is the price term and payment method?

   We can quote EXW, FOB, CIF and CFR price. And you can pay us by T/T or Western Union.
